TH 217 CROSS FLOW HEAT EXCHANGER, Water-to-Air

Enquiry

Download

The apparatus is for studying heat transfer from hot water to cross flow air such as in automobile radiator.

    The unit consists of an air duct with outlet damper, an automotive radiator, an axial flow fan and a service module. The module provided hot water tank with transfer pump and control and measuring instruments.

    Instruction manual is also supplied.

  • Demonstration of heat transfer under parallel and counter flow.



  • Determination of heat transfer coefficient.



  • Effects of flow rate and temperature difference.

  • Heat exchanger:
- Type : Finned tube
- Material : Copper/Aluminum (Cu/Al)
: Heat transfer area approximately 30,000 cm2
  • Air duct
: 250 x 250 mm
  • Pump
- Power consumption : 180 W
- Maximum flow rate : Approx. 45 LPM
  • Fan
: Axial, adjustable speed
- Power consumption : Approx. 0.12 kW
- Maximum flow rate : Approx. 30 m3/min
  • Service module consisting of :
- Stainless steel hot water tank with level switch to prevent heater operation if level is too low.
- Hot water pump :  1
- Heater : 3000 W.
- Air flow rate : Portable anemometer
- Flow meters : Hot water.
- Sensors with digital display : Temperature for hot water inlet and outlet.
for air inlet and outlet
- Temperature control unit to limit temperature of hot water.
  • Power supply                                         : 220V 1Ph 50 Hz. Other power supply is available on request.

Net (unpacked) shipping dimensions WxLxH  : 55 x 120 x 80 cm.

Net weight  : Approx. 70 kg




  • TH217-050
Computer Interface (computer not included)
 This includes TH217S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TH217-060

Computer Control (computer not included)

                                  This includes TH 217-050 with the additional accessories for control function and additional software function for equipment controls by computer



  • TH217S
Learning Software


to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
