HP 305M COMPACT SERIES AND PARALLEL PUMP TEST SET, Multi Speed

Enquiry

Video

Download

This is a self-contained bench top unit for studying the series and parallel pump characteristics at three different speeds.

The unit consists of two centrifugal pumps with multi speed motors and a storage tank on a steel base, and measuring instruments. By manipulating flow control valves, each pump can be operated individually or both pumps connected in series or parallel.

Instruction manual is also included.

  • Flow rate vs head at various speeds for individual pump

  • Flow rate vs head at a fixed speed for two pumps connected in series or parallel

  • Pump
-  Multi speed :  3 different speeds
-  Maximum flow rate :  70 LPM
-  Maximum head :  7 m water
  • Measuring instruments
-  Pressures :  Pressure gauges at pump suction and discharge
-  Flow rate :  Water meter and stop watch
  • Power supply
:  220 V, 1 Ph, 50 Hz. Other power supply is available on request.
  • Net (unassembled) Shipping Dimensions WxLxH: 60 x 110 x 70 cm
  • Net Weight:  Approx. 40 kg
  • HP305MS
Learning Software
                            to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • HP305-001
Watt meter for measurement of pump input. Hence pump efficiency can be determined.
HP305MSLearning Software
                             to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
