MP 142 AIR FLOW VISUALIZATION

Enquiry

Download

The apparatus is intended for visualization of stream lines flow around models.
The apparatus consists of a stilling entrance, a contraction section with air flow straighteners, a streamlines distributor, a viewing window, and a smoke generator.
Air flow is generated by a fan. The window has a black back ground and side lights are provided for better visualization of the streamlines. The stream lines are in a vertical pattern. Models are provided.
Instruction manual is also included.

  • Laminar and turbulence flow observation.



  • Flow patterns around bodies.



  • Boundary separation on bodies.



  • Effects of angle of attack.

  • Viewing window
:  180 x 250 mm
  • Number of streamlines
:  18
  • Smoke generator
:  1 ea. with smoke fluid
  • Models
:  1 x Aerofoil NACA 0015 profile
:  1 x Cylinder
:  1 x Plate
:  1 x Automobile
  • Power supply
:  220V 1Ph 50 Hz. Other power supply is available on request.
  • Net (unassembled) Shipping Dimensions WxLxH: 55 x 60 x 145 cm
  • Net Weight: 55 kg
MP142-001 Additional model set A: Slotted orifice, circular disc, circular orifice, sphere, hemispheres, wing tip, ISA nozzle and truck.
MP142-002 Additional model set B: Bend, bend with turning vane, corner, cylindrical tube bank.
MP142-003 Additional smoke fluid, 4 L
  • Other accessories can be supplied on request.
  • Other optional equipment, please contact manufacturer ([email protected])
