TM113A UNIVERSAL TESTING MACHINE, 30 kN.

Posted on by

Strength and properties of materials > Universal testing machine

TM113A UNIVERSAL TESTING MACHINE, 30 kN.
TM113A

Enquiry

Video

Download

This is a bench top educational simple universal testing machine.

The machine uses four in-line columns and a hand operated hydraulic jack with measuring instruments for load and displacement.

Test accessories and specimens are available as optional items.

Instruction manual is also included.

  • Tension

  • Compression

  • Bending

  • Deep draw



  • Shear



  • Brinell hardness

  • Spring compression

  • Capacity
:  30 kN
  • Maximum crosshead travel
:  50 mm
  • Measuring instruments

- Load:  Force digital display
- Displacement:  Dial indicator 0-20 mm x 0.01 mm. graduation with magnetic holder.
  • Power supply (optional version)
:  220V, 1 Ph, 50 Hz. Other power supply is available on request.


  • Net (unassembled) Shipping Dimensions WxLxH: 35 x 45 x 95 cm
  • Net Weight:  Approx. 60 kg
  • TM113-020A
Force gauge instead of force digital display.
  • TM113-010
2 screw chucks for tension test.
  • TM113-011
2 compression plates with sample springs.
  • TM113-011C
2 compression plates for compression test of non-ferrous materials.
  • TM113-012
Bending test accessories
  • TM113-013
Shear test accessories consisting of upper and lower attachment.
  • TM113-014
Accessories for Brinell hardness test
  • TM113-015
Deep draw test accessories.
  • TM113-005B
Brinell test specimen
  • TM113-005C
Compression test specimen
  • TM113-005D
Deep draw test specimen
  • TM113-005S
Shear test specimen
  • TM113-005T
Tension test specimen. The specimen has threaded heads with 6 mm. diameter test section
  • TM113-050
Computer Interface (computer not included)
                                                   This includes TM113AS and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TM113S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.

SIMILAR PRODUCTS

TH 527 REFRIGERATION TRAINER

Posted on by

Thermodynamics > Air conditioning & Refrigeration

TH 527 REFRIGERATION TRAINER
TH527

Enquiry

Video

Download

A table top refrigeration system is used to investigate energy balance at compressor, condenser and evaporator.

Both the condenser and evaporator used water cooled heat exchangers. Instruments are provided for measurement of temperatures, pressures and cooling water flow rates. The system requires outside water supply.

Instruction manual is also included.

  • Familiarization with refrigeration cycle and components.



  • p-h diagram.



  • Energy balances at evaporator and condenser.



  • Overall heat transfer coefficients for evaporator and condenser.



  • Effects of load variation.

  • Compressor
: 0.37 kW
  • Refrigerant
: R134 a
  • Condenser
: Co-axial coil heat exchanger
  • Evaporator
: Co-axial coil heat exchanger
  • Measuring instruments:

- Pressure gauges: Compressor inlet and outlet
- Water rotameters: 2x 1-7 Lpm (approx.) for heat exchangers
- Sensors with digital display: Temperature for compressor inlet and outlet, condenser outlet, evaporator inlet,


condenser and evaporator, cooling water outlets and cooling water inlet


  • Power supply
:              220V 1Ph 50Hz. Other power supply is available on request.

Net (unpacked) shipping dimensions WxLxH  : 75 x 90 x 100 cm

Net weight  : 60 kg

  • TH527S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • TH527-001
Sight glass of refrigerant at condenser exit
  • TH527-014
Cooling unit
 - Capacity : 0.75 RT
  • TH527-030
Watt meter for compressor input power
  • TH527-040
Concentric tube heat exchanger instead of co-axial coil heat exchanger
  • TH527S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

RE 490 LOW HEAD HYDRAULIC TURBINE TEST RIG

Posted on by

RENEWABLE ENERGY

RE 490 LOW HEAD HYDRAULIC TURBINE TEST RIG
RE490

Enquiry

Video

Download

This test facility was design and developed jointly with The Joint Graduate School of Energy and Environment (five institutions).        It is intended to simulate large hydro power plant discharge for end user in designing small low head turbines.

The test rig provides water flow as well as measuring instruments. Flow is generated by a centrifugal pump. A head tank in front of the test section is provided to simulate a static head and another tank is provided after the test section. Flow rate and head can be varied by an inverter. A flow control valve at the pump discharge and a flow control valve of the return line between pump discharge and pump suction are provided. A dynamometer at the test section measures the designed turbine output.

The equipment is supplied unassembled and to be erected and commissioned at site.

Instruction manual is also included.

       This is an ideal facility to simulate flow conditions of the actual site. The turbine input (flow rate and head) and output (speed and torque) can be accurately monitored. Thus, the most efficient prototype turbine can be designed, developed and tested.

  • Pump ratings
:               Maximum flow rate 1300 m3/h
 :               Maximum head 15 m H2O
  • Circulating pipe
:               300 mm diameter
  • Test section
:               300 mm diameter x 750 mm long
  • Dynamometer
:               Water brake absorber, 30 kW rating
  • Head tank at upstream of test section
:               950 mm diameter x 3 m long
  • Tail tank after test section
:               1430 mm diameter x 2.2 m long
  • Sensors with digital display
:               Flow rate
 :               Turbine pressures at test section entrance and exit
 :               Speed
 :               Torque
  • Steel base frame with supports for tanks and pipings, test section platform with ladder.
  • Software for data display and analysis by computer (separately supplied)
  • Power supply         :   380V, 3Ph, 50Hz. Other power supply is available on request.
  • Working dimensions WxLxH:  4.4 x 7.8 x 3.0 m
  • Net (unpacked) Shipping Dimensions WxLxH: Approx. One 40 ft. container
  • Net Weight:  Approx. 3500 kg
  • RE490-050
Computer Interface (computer not included)
                                          This includes HT990S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)





  • RE490S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

TH 525 AIR – TO – WATER HEAT PUMP

Posted on by

Thermodynamics > Air conditioning & Refrigeration

TH 525 AIR - TO – WATER HEAT PUMP
TH 525

Enquiry

Video

Download

A table top air conditioning system is used to demonstrate how heat is transferred from air to water.

A water cooled heat exchanger is used as a condenser while the liquid refrigerant is evaporated in an air cooled evaporator. Instruments are provided for measurement of temperatures, pressures, and water flow rate. The system requires outside water supply.

Instruction manual is also included.

  • Design and operation of air to water heat pump.



  • P-h diagram.



  • Energy balances.



  • Coefficient of performance.



  • Overall heat transfer coefficients for evaporator and condenser.



  • Effects of loads variation.

  • Compressor
 :   0.37 W
  • Refrigerant
 :   R134a
  • Evaporator
 :   Air cooled
  • Condenser
 :   Co-axial coil heat exchanger
  • Measuring instruments:
- Pressure gauges : Compressor inlet and outlet.
- Water rotameter : 1-7 Lpm (approx.)
- Sensors with digital display : Temperatures for compressor inlet and outlet, condenser outlet, evaporator inlet, condenser cooling water inlet and outlet, and air -side of evaporator inlet and outlet.
  • Accessory
 : Pressure switch
  • Power supply
 : 220V 1Ph 50Hz. Other power supply is available on request.

Net (unpacked) shipping dimensions WxLxH  : 80 x 95 x 75 cm

Net weight  : 60 kg

  • TH525S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • TH525-001
Sight glass of refrigerant at condenser exit
  • TH525-014
Cooling unit



- Capacity : 0.75 RT
  • TH525-030
Watt meter for compressor input power
  • TH525-040
Concentric tube heat exchanger instead of co-axial coil heat exchanger
  • TH525S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

TH 522 ICE MAKER TEST RIG

Posted on by

Thermodynamics > Air conditioning & Refrigeration

TH 522 ICE MAKER TEST RIG
TH 522

Enquiry

Video

Download

This table top refrigeration system is intended for studying ice making process.

The unit comprises a typical refrigeration system whereby a small ice maker is used for evaporator. Instruments are provided for measurement of pressures and temperatures.

Instruction manual is also included.

  • Familiarization with ice making system and components.



  • P-h diagram.



  • Coefficient of performance.

  • Ice making unit
 :   0.4 kg/h
  • Refrigerant
 :   R134A
  • Measuring instruments:
- Pressure gauges : Compressor inlet and outlet
- Sensors with digital display : Temperatures for compressor inlet and outlet, evaporator inlet, condenser outlet and ice/water in the ice tank
  • Accessory
 : Pressure switch
  • Power supply
 : 220 V, 1 Ph, 50Hz. Other power supply is available on request.

Net (unpacked) shipping dimensions WxLxH  : 65 x 90 x 65 cm

Net weight  : 50 kg

  • TH522S
 Learning Software
to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • TH522-001
 Sight glass of refrigerant at condenser exit
  • TH522-030
 Watt meter for compressor input power.
  • TH522S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

TH 520 BASIC REFRIGERATION SYSTEM

Posted on by

Thermodynamics > Air conditioning & Refrigeration

TH 520 BASIC REFRIGERATION SYSTEM
TH 520

Enquiry

Video

Download

This unit is used for demonstration of a normal household refrigerator operation. Individual components are clearly shown. Temperatures and pressures at various points are indicated. Sight glasses are provided to indicate the state of the refrigerant.

Instruction manual is also included.

  • Study of layout and process diagram.



  • Observation of pressures and temperatures.



  • Using a p-h state diagram.

  • Compressor
- Type : Hermetic
- Size : Approx. 70 W
  • Condenser
 : Tube with wire grid
  • Evaporator
 : Circular chamber
  • Refrigerant
 : R134a
  • Sight glasses
 : 3 at compressor exit, condenser exit and evaporator exit
  • Measuring instruments
- Pressure gauges : Compressor inlet and outlet
- Sensors with digital display : Temperature for compressor inlet and outlet, condenser outlet, after expansion valve and in refrigerator
  • Power supply
 : 220 V, 1 Ph, 50Hz. Other power supply is available on request.

Net (unpacked) shipping dimensions WxLxH  : 50 x 95 x 35 cm

Net weight  : Approx. 48 kg

  • TH520S
 Learning Software
to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • TH520S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

RE 440 MINI HYDRO POWER PLANT

Posted on by

RENEWABLE ENERGY

RE 440 MINI HYDRO POWER PLANT
RE440

Enquiry

Video

Download

This is a self contained bench top unit for studying the power generation by a hydraulic turbine.

The unit consist of a storage tank and a low head pump to simulate a dam reservoir, a cross flow hydraulic turbine, a generator which is connected to the turbine by a V-belt, a lamp load bank a dynamometer, and measuring instrument.

The dynamometer is on the same shaft as the turbine, and the generator is connected to the turbine by v-belt.

Instruction manual is also included.

  • Turbine torque vs speed at various heads and flow rates

  • Mechanical power output vs speed for various heads and flow rates

  • Mechanical efficiency vs speed for a given head and flow rate

  • Electrical power output at various heads and flow rates

  • Overall power plant efficiency at various electrical loads

  • Turbine:

- Type:  Cross Flow
- Construction:  Stainless steel runner and nozzle
 :  Stainless steel casing with transparent window
- Ratings :  Maximum power over 400 W of mechanical output or Approx. 300 W electrical output
  • Pump ratings

-  Motor:  2.2 kW
  • Generator
:  0.75 kVA, 220 V, 1 Ph, 50 Hz.
  • Electrical load
:  Lamp bank
  • Dynamometer
:  Water cooled stainless steel mechanical brake with anti splashing system.
  • Measuring instruments

- Torque:  Spring balance
- Pressure:  Pressure gauge
- Sensors with digital display:  Voltage and current for electrical output power
 :  Speed for turbine and generator
 :  Flow rate
  • Power supply
:  220 V, 1 Ph, 50 Hz. Other power supply is available on request.



  • Net (unassembled) Shipping Dimensions WxLxH: 80 x 140 x 105 cm
  • Net Weight:  Approx. 155 kg
  • Other type of turbine instead of cross flow turbine
  • HD160SA
Water brake absorber instead of mechanical brake absorber
  • RE440-050
Computer Interface (computer not included)
 This includes RE440S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • RE440-060
Computer Control (computer not included)
                                This includes RE440-050 with the additional accessories for control function and additional software function for equipment controls by computer
  • RE440S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

TH 518 RECIRCULATING AIR CONDITIONING UNIT, With Climatic Chamber

Posted on by

Thermodynamics > Air conditioning & Refrigeration

TH 518 RECIRCULATING AIR CONDITIONING UNIT, With Climatic Chamber
TH 518

Enquiry

Video

Download

This is a recirculating air conditioning unit with transparent windows and a climatic chamber.

Inlet air is cooled by a refrigeration system, heated by a preheater, and added moisture or latent heat by a humidifier before entering the climatic chamber for demonstration of climate control. The air in the climatic chamber is further heated by a reheater and a humidifier before leaving. A fan installed after the preheater is used to circulate the air in the duct. Part of the air leaving the climatic chamber is vented and the remaining is recirculated and mixed with fresh air entering the inlet duct. The amount of air recirculation is controlled by ventilation dampers. Steam generator, compressor and condenser are installed underneath the duct.

Measuring instruments are provided for air flow rate, and temperature and humidity at various stages. Additional instruments are provided for measurement of refrigerant flow rate, temperature and pressure as well as power for the compressor and heat sources.

The unit is on steel frame on wheels.

Instruction manual is also included.

  • Familiarization with recirculating air conditioning system and components.



  • Determination of preheating, cooling and dehumidification, humidification, and reheating processes.



  • Energy balance in the preheater, evaporator, and reheater.



  • Demonstration of preheating, cooling and dehumidification, humidification, reheating, and mixing processes on psychrometric chart.



  • Demonstration of refrigeration cycle on Pressure-Enthalpy diagram of the refrigerant R134a.



  • Determination of recirculating and mixing process of moist air.



  • Effects of climatic chamber heat loads.

  • Air duct
: 250 x 250 mm, stainless steel sheet
  • Climatic chamber
: Approx. 180 L
  • Fan
: Adjustable speed
- Maximum airflow rate: Approx. 750 m3/h
  • Humidifier
: 3000 W, adjustable.
  • Preheater
: 1200W, adjustable
  • Reheater
: 600W, adjustable
  • Heater controller
: 1
  • Evaporator
: 250 x 250 mm
  • Compressor
: Approx. 0.55 kW.
  • Condenser
: with fan
  • Refrigerant
: R134a
  • Temperature controller
: 1
  • Measuring instruments

- Sensors with digital display: Air flow rate, velocity sensor
 : Temperatures at duct inlet, evaporator inlet, humidifier inlet, humidifier outlet ,
 reheater inlet and outlet, compressor inlet and outlet and condenser outlet.
 : Power measurement for compressor, humiditier, preheater and reheater
- Portable temperature/humidity meter: 0-50°C, 10-90% RH, at duct inlet, preheater inlet and climatic chamber outlet
- Refrigerant rotameter
- Pressure gauges : Compressor inlet and outlet
  • Power supply
: 380 V 3 Ph 50 Hz. Other power supply is available on request.

Net (unpacked) shipping dimensions WxLxH  : 70 x 270 x 185 cm

Net weight  : 320 kg

  • TH518S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • TH516-001

Humidity digital display instead of portable temperature/humidity meter

  • TH518-050

Computer Interface (computer not included)

                     This includes TH518S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)

  • TH516S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

RE 310 EDUCATIONAL WIND TURBINE, Computer Interface

Posted on by

RENEWABLE ENERGY

RE 310 EDUCATIONAL WIND TURBINE, Computer Interface
RE 310

Enquiry

Video

Download

The unit is for a study of wind turbine characteristics.

The turbine consists of axial flow fan with speed control and flare entrance, a wind turbine, DC generator with resistance load, dynamometer, and measuring instruments. The turbine and blade angle can be adjusted using a special device. The unit can also be used for testing different blade design by students.

Instruction manual is also included.

  • Calculation of wind power.

  • Turbine output VS wind speed.

  • Turbine efficiency.

  • Effect of blade angle.

  • Effect of number of blades.

  • Effect of yaw angle adjustment (optional)

  • Fan

- Diameter:  500 mm inside diameter
- Maximum wind speed:  20 m/s
  • Wind speed control
:  Inverter
  • Turbine casing
:  Steel, 500 mm inside diameter × 500 mm long, with transparent window and front guard.
  • Turbine blade angle setting device

  • Generator dynamometer
:  1
  • Electrical load
:  1
  • Turbine output

- Maximum mechanical power:  130 W
  • Measuring instruments

- Wind speed:  Pitot tube
- Sensors with digital display:  Speed for turbine
 :  Torque
 :  Voltage and current for electrical output power
  • Power supply
:  220V, 1 Ph, 50 Hz. Other power supply is available on request.
  • Computer interface unit
  • Software for data display and analysis by computer (separately supplied)
  • WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • Net (unassembled) Shipping Dimensions WxLxH: 65 x 120 x 100 cm
  • Net Weight:  Approx. 90 kg
  • RE310-001
Transparent turbine casing instead of standard steel casing
  • RE310-002
Yaw angle adjustment ability
  • RE310-003
Battery and lamp load
  • RE310-004
Different set of blade shape


SIMILAR PRODUCTS

TH 516 LABORATORY AIR CONDITIONING SYSTEM

Posted on by

Thermodynamics > Air conditioning & Refrigeration

TH 516 LABORATORY AIR CONDITIONING SYSTEM
TH 516
TH516-2

Enquiry

Video

Download

This is an open circuit air conditioning system with transparent window.

The unit consists of a fan, a compressor and condenser, a humidifier, a preheater, a cooling unit, a reheater, and measuring instruments.

Variable speed inlet fan deliver air to the duct. A steam humidifier injects moisture to the duct inlet. The humidified air passes through a preheater, a cooling unit, and a reheater before exit to the atmosphere. Steam generator, compressor and condenser are underneath the duct.

Instruments are provided for measurement of temperatures, pressures, humidity, power, air flow rate, and refrigerant flow rate.

The unit is on a steel frame on wheels.

Instruction manual is also included.

  • Familiarization with an open air conditioning system and components.



  • Determination of humidification, preheating, cooling and dehumidification, and reheating processes.



  • Energy balance in the preheater, evaporator, and reheater.



  • Demonstration of humidification, preheating, cooling and dehumidification, and reheating processes on psychrometric chart.



  • Demonstration of refrigeration cycle on Pressure-Enthalpy diagram of the refrigerant R134a.

  • Air duct
 : 250 x 250 mm, stainless steel sheet
  • Fan with speed controller
- Maximum airflow rate : 750 m3/h
  • Humidifier
 : 1500 W, adjustable
  • Preheater
 : 1500 W, adjustable
  • Reheater
 : 1500 W, adjustable
  • Heater controller
 : 1
  • Evaporator
 : 250 x 250 mm
  • Compressor
 : 0.55 kW
  • Condenser
 : with fan
  • Refrigerant
 : R134a
  • Temperature controller
 : 1
  • Measuring instruments
- Sensors with digital display : Air flow rate, velocity sensor
: Temperature at duct inlet, humidifier, preheater inlet and outlet, evaporator outlet,
reheater outlet, compressor inlet and outlet and condenser outlet.
: Power for compressor, humidifier, preheater and reheater
- Refrigerant rotameter
- Portable temperature / humidity meter : 0-50oC, 10-90% RH
- Pressure gauges : Compressor inlet and outlet
  • Power supply
 : 380 V, 3 Ph, 50Hz. Other power supply is available on request.

Net (unpacked) shipping dimensions WxLxH  : 70 x 195 x 135 cm

Net weight  : Approx. 200 kg

  • TH516S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • TH516-001
Humidity digital display instead of portable temperature/humidity meter.
  • TH516-050
Computer Interface (computer not included)
 This includes TH516S and significant sensor(s) instead of analog measuring instrument(s),
 data acquisition (capture, display, graph and/or data export),


additional software function for real-time data logging with computer interface unit and

 WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)

  • TH516S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS
