ST 376 TORSION AND BENDING

Posted on by

Structure and accessories > Torsion

ST 376 TORSION AND BENDING

Enquiry

Video

Download

The apparatus is used for torsion and bending tests on different materials. It is to be used with ST305 Universal Base Frame or ST300 Universal Structural Frame (separately supplied) for attachment of the accessories.

The apparatus consists of two columns attached to the base frame. One column has a top support for bending specimen, and a clamp for torsion specimen. The other column also has a top support for bending specimen with a pulley freely rotates in the column.

For bending test, the specimen is placed on or clamped to the supports on top of the columns. Load is applied to the specimen and deflection is measured by a dial gauge.

For torsion test, one end of the specimen is clamped to one of the column. The other end of the specimen is clamped to the pulley. A lever arm is attached to the specimen at any length from the first column for measurement of the angle of twist. Angle of twist is measured by a dial gauge for the lever movement. Torque is measured by the load and the pulley diameter.

Instruction manual is also included.

  • Bending moment variation at the point of loading

  • Variation of bending moment away from the point of loading

  • Examination of various other loading cases

  • Specimens
:              Round for steel, aluminum and brass
 :              Flat for steel, aluminum and brass
  • Columns
:              One with fixed specimen clamp, and one with rotating specimen clamp
  • Bending supports
:               2 round
 :               2 fixed with knife edge top
  • Load hanger
:               1
  • Rotating arm
:               1
  • Weights
:               1 lot
  • ST131 Dial Indicator
:               1




  • Net (unassembled) Shipping Dimensions WxLxH: 40 x 70 x 15 cm
  • Net Weight:  Approx. 10 kg
  • ST376S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • ST376-055
Computer Assist (computer not included)
                                         This includes ST376S and significant sensor(s) with data acquisition (capture, display, graph and/or data export) instead of analog measuring instrument(s), additional software function for real-time data logging with computer assist unit and WiFi feature for data logging and display remotely on smartphone (iOS and Android)
  • ST376S
Learning Software
                                 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

ST 375 TORSION OF RODS AND TUBES

Posted on by

Structure and accessories > Torsion

ST 375 TORSION OF RODS AND TUBES

Enquiry

Video

Download

The equipment is used for the investigation of torsion and torsional rigidity in rods, and tubes. It is to be used with ST305 Universal Base Frame or ST300 Universal Structural Frame (separately supplied) for attachment of the accessories.

The apparatus consists of two columns attached to the base frame. One end of the specimen is clamped to one of the column. A lever arm is attached to the specimen at any test length from the first column for measurement of the angle of twist. A pulley for load hanging can be freely rotated in the second column. The other end of the specimen is clamped to the pulley.

Angle of twist is measured by a dial gauge for the lever movement. Torque is measured by the load and pulley diameter.

Instruction manual is also included.

  • The relationship between specimen length, torque and angular deflection

  • The behavior of specimens of different materials and cross-sections

  • Comparison of angular deflection in similar hollow and solid rods.

  • Polar moment of inertia.

  • Specimens, 650 mm long
:  Rod and tube
  • Materials
:  Steel and brass
  • Columns
:  One with fixed specimen clamp and one with rotating specimen clamp with pulley
  • Load hanger
:  1
  • Weights
:  1 lot.
  • Rotating arm
:  1
  • Cord
:  1
  • ST131 Dial Indicator
:  1





  • Net (unassembled) Shipping Dimensions WxLxH: 40 x 70 x 15 cm
  • Net Weight:  Approx. 10 kg
  • ST375S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • ST375-055
Computer Assist (computer not included)
                                         This includes ST375S and significant sensor(s) with data acquisition (capture, display, graph and/or data export) instead of analog measuring instrument(s), additional software function for real-time data logging with computer assist unit and WiFi feature for data logging and display remotely on smartphone (iOS and Android)
  • ST375S
Learning Software
                                 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

ST 345 TENSILE MODULUS OF ELASTICITY

Posted on by

Structure and accessories > Strength of material

ST 345 TENSILE MODULUS OF ELASTICITY

Enquiry

Video

Download

This equipment is used for studying the modulus of elasticity of materials in the form of rods. It is to be used with ST300 Universal Structural Frame (separately supplied) for attachment of the accessories.

The rod is mounted between two gripping heads and a load is applied by means of screw with turning wheel. The load is measured by load cell with force indicator. Elongation of the gauge length is measured by extensometer.

Instruction manual is also included.

  • Modulus of elasticity of materials

  • Test rod
:  Mild steel, brass and aluminum
  • Test rod holders
:  2
  • Extensometer with output
:  1
  • Loading device
:  Screw with a turning wheel
  • Force measurement
:  Load cell with ST 150 Force Indicator
  • Power supply
:  220 V, 1 Ph, 50Hz. or as required







  • Net (unassembled) Shipping Dimensions WxLxH: 30 x 55 x 20 cm
  • Net Weight:  Approx. 5 kg
  • ST345S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • ST345S
Learning Software
                                 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

ST 343 STRAIN GAUGES

Posted on by

Structure and accessories > Strength of material

ST 343 STRAIN GAUGES

Enquiry

Video

Download

The apparatus demonstrates the use of electrical resistance strain gauge in measuring strain of material under bending, torsion or combined bending and torsion stresses. It is to be used with ST305 Universal Base Frame (separately supplied) for attachment of the accessories.

Two specimens are used. The specimen is mounted horizontally on a support column at one end. A cantilever beam for bending load, a rod with torsion arm for bending and torsion load and a strip for tension load. Strain gauges are placed on to the specimens. Each strain gauge is wired to form a full bridge with temperature compensation and zero adjustment. Strain is indicated on the strain indicator.

Instruction manual is also included.

  • Fundamentals of measuring with strain gauges

  • Correlation between mechanical strain and electrical resistance in a strain gauge

  • Calculation of the mechanical deformations under bending, torsion or combined bending and torsion

  • Test beams with Strain Gauge
:  Aluminum beam for bending test
 :  Aluminum rod with arm for torsion test
  • ST 113 Built-in/knife edge support
:  1
  • ST 151 Strain indicator
:  1
  • Load hanger
:  1
  • Weights
:  1 lot
  • Power supply
:  220 V, 1 Ph, 50Hz. or as required






  • Net (unassembled) Shipping Dimensions WxLxH: 70 x 90 x 20 cm
  • Net Weight:  Approx. 20 kg
  • ST343S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • ST343-055
Computer Assist (computer not included)
                                    This includes ST343S and significant sensor(s) with data acquisition (capture, display, graph and/or data export) instead of analog measuring instrument(s), additional software function for real-time data logging with computer assist unit and WiFi feature for data logging and display remotely on smartphone (iOS and Android)
  • ST343S
Learning Software
                                 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

ST 340 STRAIN AND STRESS IN A BEAM

Posted on by

Structure and accessories > Strength of material

ST 340 STRAIN AND STRESS IN A BEAM

Enquiry

Video

Download

The apparatus demonstrates the use of electrical resistance strain gauge in measuring strain of material under stress. It is to be used with ST300 Universal Structural Frame or ST305 Universal Base Frame (separately supplied) for attachment of the accessories.

A beam is simply supported at both ends. Strain gauge(s) are fixed at different locations of the beam specimen. Each strain gauge is wired to form a full bridge with temperature compensation and zero adjustment. Load is applied by a load hanger and weights. Strain(s) are measured by a strain indicator.

Instruction manual is also included.

  • Examination of the relationship between stress and strain

  • Finding the neutral axis

  • The effect of beam cross-section to the second moment of area and neutral axis

  • Test beams
: Aluminium, different shapes
  • ST 113 Built-in/Knife Edge Supports
: 2
  • ST 151 Strain Indicator
: 1
  • Load hanger
: 1
  • Weights
: 1 lot
  • Power supply
: 220 V, 1 Ph, 50Hz. or as required







  • Net (unassembled) Shipping Dimensions WxLxH: 70 x 80 x 20 cm
  • Net Weight:  Approx. 12 kg
  • ST340S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • ST340-055
Computer Assist (computer not included)
                                    This includes ST340S and significant sensor(s) with data acquisition (capture, display, graph and/or data export) instead of analog measuring instrument(s), additional software function for real-time data logging with computer assist unit and WiFi feature for data logging and display remotely on smartphone (iOS and Android)
  • ST340S
Learning Software
                                 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

ST 370 COLUMN BUCKLING

Posted on by

Structure and accessories > Deflection and stress

ST 370 COLUMN BUCKLING

Enquiry

Video

Download

The equipment is used for studying strut buckling under load. It is to be used with ST300 Universal Structural Frame (separately supplied) for attachment of the accessories.

The top frame has a loading screw which pushes a cylindrical strut support sliding in a bushing. The bottom frame has a load cell and a cylindrical strut support in a socket.

Each strut has end conditions for knife-edge or built – in. The load reading is by an indicator. A small lateral load is applied by means of a pulley and a load hanger. A dial indicator measures the lateral deflection.

Instruction manual is also included.

  • Euler buckling loads

  • Relationship between strut length and collapse load

  • Relationship between various end-fixing conditions and collapse load

  • Nature of deflection and deflected shapes with various end-fixing conditions

  • Top support with a loading screw

  • Bottom support with a load cell
:   1
  • ST150 Force indicator
:   1
  • Strut specimens:

- Materials:   Mild steel, brass, aluminum
  • Strut supports:

- Built in:   2
- Knife - edges:   2
  • Horizontal load hanger set
:   1
  • Pulley set
:   1
  • Hanger slider
:   1
  • Cord
:   1
  • Load hanger
:   1
  • Weights
:   1 lot
  • ST131 Dial indicator
:   1
  • Power supply
:   220 V, 1 Ph, 50Hz. Other power supply is available on request.



  • Net (unassembled) Shipping Dimensions WxLxH: 45 x 60 x 15 cm
  • Net Weight:  Approx. 12 kg
  • ST370S
Learning Software



to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • ST370S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

ST 365 DEFLECTION OF CURVED BARS

Posted on by

Structure and accessories > Deflection and stress

ST 365 DEFLECTION OF CURVED BARS

Enquiry

Video

Download

This equipment is used for measurement of horizontal and vertical components of curved bar deflections, and comparison of measured values with theoretical ones. It is to be used with ST300 Universal Structural Frame (separately supplied) for attachment of the accessories.

The apparatus consists of curved bar clamped at one end. Load is applied and deflections are measured on the free end by dial indicators.

Instruction manual is also included.

  • Investigation of the relationship between load, horizontal deflection and vertical deflection

  • Elastic bending.

  • Curved bars, Steel 19 x 3 (approx.) mm cross section

-  Quadrant

-  Semicircle

-  Ring

  • Load hanger
:  1
  • Weights
:  1 lot
  • ST131 Dial Indicators
:  2










  • Net (unassembled) Shipping Dimensions WxLxH: 35 x 55 x 15 cm
  • Net Weight:  Approx. 8 kg
  • ST365S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • ST365-055
Computer Assist (computer not included)
                                    This includes ST365S and significant sensor(s) with data acquisition (capture, display, graph and/or data export) instead of analog measuring instrument(s), additional software function for real-time data logging with computer assist unit and WiFi feature for data logging and display remotely on smartphone (iOS and Android)
  • ST365S
Learning Software
                                 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

ST 362 PLASTIC BENDING OF A FRAME, Computer Assist

Posted on by

Structure and accessories > Deflection and stress

ST 362 PLASTIC BENDING OF A FRAME, Computer Assist

Enquiry

Video

Download

This equipment allows a study on the relation between deflection of a portal frame under loads in plastic condition. It is to be used with ST300 Universal Structural Frame (separately supplied) for attachment of the accessories.

A portal frame is fixed at both legs on two supports. Loads are applied vertically on the cross member and/or horizontally on one of the legs by force load cell. Deflection of the frame is measured by long stroke displacement force load cell. Loads are applied until frame collapses.

Instruction manual is also included.

  • Elastic bending to plastic deformation of portal frames.

  • Collapse load and the formation of plastic hinges.

  • Deformation due to single and combined loads on a portal frame.

  • Shape of a collapsed portal due to hinge formation.

  • Frame
:  Annealed steel 200x300 mm portal with 2x15 mm (approx.) section
  • ST150 Force Indicator
:  1
  • ST125L Vertical Force Load Cell, Long
:  1
  • Supports
:  2
  • Cord
:  1
  • Power supply
:  220V, 1Ph, 50Hz. Other power supply is available on request.







  • Net (unassembled) Shipping Dimensions WxLxH: 60 x 70 x 20 cm
  • Net Weight:  Approx. 14 kg
  • SP362-005              Spare frame
 :  Pack of 10
  • ST362-010              Vernier
 :  0-150 mm, 0.01 mm graduation


SIMILAR PRODUCTS

ST 361 BENDING MOMENT IN A FRAME

Posted on by

Structure and accessories > Deflection and stress

ST 361 BENDING MOMENT IN A FRAME

Enquiry

Video

Download

This equipment allows measurement of strain hence bending moment along the length of the vertical and horizontal members of a rectangular portal frame. It is to be used with ST300 Universal Structural Frame (separately supplied) for attachment of the accessories.

Strain gauges are fixed at equal distance along the frame members, 8 on the horizontal member and 4 on each vertical member. Both vertical legs of the frame can be clamped to ST300 Universal Structural Frame. Loads can be applied on the horizontal and/or vertical members and/or removable moment arm of the frame. Strains on the frame can be measured by the strain indicator. Bending moment at each strain gauge can be calculated from the strain and compared with the theoretical value.

Instruction manual is also included.

  • Relationship between measured strain and bending moment.

  • Elastic bending of portal frames and linear relationship between the bending moments in the frame and the load.

  • Bending moments for internal and external moments on vertical members

  • Comparison of ideal and non-ideal structures

  • Portal frame

:   200x400 mm with 19x6 mm (approx.) section with 16 strain gauges

  • ST153 Strain Indicator
:  16 channels
  • Cord
:  1
  • Load hangers
:  2
  • Weights
:  1 lot
  • Pulley set
:  1
  • ST131 Dial Indicator
:  1
  • Power supply
:  220V, 1Ph, 50 Hz. Other power supply is available on request.





  • Net (unassembled) Shipping Dimensions WxLxH: 75 x 75 x 20 cm
  • Net Weight:  Approx. 14 kg
  • ST361S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • ST361-055
Computer Assist (computer not included)
                                    This includes ST361S and significant sensor(s) with data acquisition (capture, display, graph and/or data export) instead of analog measuring instrument(s), additional software function for real-time data logging with computer assist unit and WiFi feature for data logging and display remotely on smartphone (iOS and Android)
  • ST361S
Learning Software
                                 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

ST 360 DEFLECTIONS AND REACTIONS OF FRAMES

Posted on by

Structure and accessories > Deflection and stress

ST 360 DEFLECTIONS AND REACTIONS OF FRAMES

Enquiry

Video

Download

This equipment allows comparison of experimental and theoretical deflections and reactions of a rectangular portal and an “S” frame when loads are applied. It is to be used with ST300 Universal Structural Frame (separately supplied) for attachment of the accessories.

The frame is made of steel bar with a fixed leg while the other leg can be moved horizontally. Loads are applied vertically and/or horizontally. Moment at the frame fixed leg is measured by a moment support and a horizontal force on the frame free leg is measured by a horizontal force support. Deflection of the frame is measured by a dial indicator.

Instruction manual is also included.

  • Horizontal reaction and fixing moment due to a varying single point load

  • Comparison of behavior to simplified theory

  • Portal frame

:  200x400 mm with 19x6 mm (approx.) section

  • “S” frame
:  Center limb 300 mm and all other members 150 mm
  • ST115 Moment Support
:  1
  • ST119 Horizontal Force Support
:  1
  • Load hangers
:  2
  • Weights
:  1 lot
  • Pulley set
:  1
  • ST131 Dial Indicators
:  3





  • Net (unassembled) Shipping Dimensions WxLxH: 55 x 90 x 15 cm
  • Net Weight:  Approx. 14 kg
  • ST360S
Learning Software
 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
  • ST360-055
Computer Assist (computer not included)
                                    This includes ST360S and significant sensor(s) with data acquisition (capture, display, graph and/or data export) instead of analog measuring instrument(s), additional software function for real-time data logging with computer assist unit and WiFi feature for data logging and display remotely on smartphone (iOS and Android)
  • ST360S
Learning Software
                                 to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS
