TH 217 CROSS FLOW HEAT EXCHANGER, Water-to-Air

Thermodynamics > Heat exchangers

TH 217 CROSS FLOW HEAT EXCHANGER, Water-to-Air

Enquiry

Download

The apparatus is for studying heat transfer from hot water to cross flow air such as in automobile radiator.

    The unit consists of an air duct with outlet damper, an automotive radiator, an axial flow fan and a service module. The module provided hot water tank with transfer pump and control and measuring instruments.

    Instruction manual is also supplied.

  • Demonstration of heat transfer under parallel and counter flow.



  • Determination of heat transfer coefficient.



  • Effects of flow rate and temperature difference.

  • Heat exchanger:
- Type : Finned tube
- Material : Copper/Aluminum (Cu/Al)
: Heat transfer area approximately 30,000 cm2
  • Air duct
: 250 x 250 mm
  • Pump
- Power consumption : 180 W
- Maximum flow rate : Approx. 45 LPM
  • Fan
: Axial, adjustable speed
- Power consumption : Approx. 0.12 kW
- Maximum flow rate : Approx. 30 m3/min
  • Service module consisting of :
- Stainless steel hot water tank with level switch to prevent heater operation if level is too low.
- Hot water pump :  1
- Heater : 3000 W.
- Air flow rate : Portable anemometer
- Flow meters : Hot water.
- Sensors with digital display : Temperature for hot water inlet and outlet.
for air inlet and outlet
- Temperature control unit to limit temperature of hot water.
  • Power supply                                         : 220V 1Ph 50 Hz. Other power supply is available on request.

Net (unpacked) shipping dimensions WxLxH  : 55 x 120 x 80 cm.

Net weight  : Approx. 70 kg




  • TH217-050
Computer Interface (computer not included)
 This includes TH217S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TH217-060

Computer Control (computer not included)

                                  This includes TH 217-050 with the additional accessories for control function and additional software function for equipment controls by computer



  • TH217S
Learning Software


to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.

SIMILAR PRODUCTS

TM 445 CIRCULAR DIAPHRAGM

Enquiry

Video

Download

The equipment is used for studying the stress and deflection of a thin diaphragm.

The circular aluminum alloy diaphragm is clamped around its edge by two heavy steel flanges. Internal pressure is applied to the diaphragm by a hydraulic hand pump. Pressure in the diaphragm is indicated on a pressure gauge. A dial gauge is fitted onto a cross bar to measure the diaphragm surface profile. Scale on the cross bar indicates the dial gauge position.

Strain gauges are of the same gauge factor and the gauges are fitted onto the diaphragm at different angles and radii. Each strain gauge is wired to form a full bridge with temperature compensation gauge and zero adjustment in a bridge box with strain gauge indicator.

Instruction manual is also included.

  • Deflection of circular diaphragm under pressure

  • Strains on the diaphragm surface under pressure

  • Diaphragm :

- Effective diameter:  200 mm
- Maximum internal pressure:  60 kN/m2
  • Pressure gauge
:  1 kg/cm2
  • Number of strain gauges
:  8 ea.
  • Dial gauge
:  0-20 mm x 0.01 mm graduation
  • Strain indicator
:  8 channels
  • Power supply
:  220V, 1 Ph, 50Hz. Other power supply is available on request.


  • Net (unpacked) Shipping Dimensions WxLxH: 60 x 65 x 41 cm
  • Net Weight:  Approx. 31 kg
  • TM445-050
Computer Interface (computer not included)
                                   This includes TM445S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TM445S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.

SIMILAR PRODUCTS

TM 442 THICK CYLINDER

Enquiry

Video

Download

The equipment is used for studying a stress profile in the wall of a thick cylinder.

Two halves of thick aluminum alloy cylinders are cemented and clamped together. A hand operated hydraulic pump transmits pressure to the inside of the cylinders via the clamping bolt. The pressure is indicated by a pressure gauge.

Strain gauges are of the same gauge factor and the gauges are attached radially and circumferentially along the wall thickness and filled with jointing material. Additional strain gauges are attached on the inside and outside surfaces of the cylinder.  Each strain gauge is wired to form a full bridge with temperature compensation gauge and zero adjustment in a bridge box with strain gauge indicator.

Instruction manual is also included.

  • Measurement of strains, hence stresses, along the cylinder wall thickness.

  • Comparison of the actual strain readings with theoretical values.

  • Cylinder

- Length:  300 mm
- Outer diameter:  180 mm
- Maximum internal pressure:  7 N/mm2
  • Pressure gauge
:  100 kg/cm2
  • Strain gauges
:  14 ea. at different angles.
  • Strain indicator
:  16 channels
  • Power supply
:  220V, 1 Ph, 50Hz. Other power supply is available on request.


  • Net (unpacked) Shipping Dimensions WxLxH: 60 x 65 x 48 cm
  • Net Weight:  Approx. 48.5 kg
  • TM442-050
Computer Interface (computer not included)
                                   This includes TM442S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TM442S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.

SIMILAR PRODUCTS

TM 441 THIN CYLINDER

Enquiry

Video

Download

This equipment is used for studying the stresses in a thin wall cylinder.

A thin wall aluminum alloy cylinder is mounted on a rigid steel frame. Internal pressure is applied to the cylinder by means of a hydraulic hand pump with oil reservoir. Pressure in the cylinder is indicated on a pressure gauge. A screw is attached on a frame to open or close one side of the cylinder. When the cylinder is open, only circumferential stress occurs on the cylinder. When the cylinder is closed, both circumferential and axial stresses occur.

Strain gauges are of the same gauge factor and the gauges are fixed onto the cylinder at different angles. Each strain gauge is wired to form a full bridge with temperature compensation gauge and zero adjustment in a bridge box with strain gauge indicator.

Instruction manual is also included.

  • Measurement of strains and stresses under internal pressures.

  • Determination of Young’s modulus a Poisson’s ratio.

  • Comparison of theoretical stresses and strains with experimental values.

  • Cylinder

- Length:  360 mm
- Outer diameter:  80 mm
- Maximum internal pressure:  3.5 N/mm2
  • Pressure gauge
:  50 kg/cm2
  • Strain gauges
:  6 ea. at different angles.
  • Strain indicator
:  8 channels
  • Power supply
:  220V, 1 Ph, 50Hz. Other power supply is available on request.


  • Net (unpacked) Shipping Dimensions WxLxH: 60 x 65 x 48 cm
  • Net Weight:  Approx. 35 kg
  • TM441-050
Computer Interface (computer not included)
                                   This includes TM441S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TM441S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.

SIMILAR PRODUCTS

TM 415 BEAM APPARATUS

Enquiry

Video

Download

This beam apparatus is of a universal design for use in a wide range of beam experiments with simple, built-in and sinking supports measuring of, point loads, support reactions and beam deflections.

The beam frame consists of a stainless steel angle upper cross member and two aluminum profile lower cross members, bolted to the support columns with footings.  Three spring load cells with height adjustment and a cantilever support can slide along the lower members and can be clamped at any point.  Dial indicators can slide along the upper member and can be clamped at any point.  Linear scale is attached to the upper member to indicate the positions of load cells, loads, supports and dial indicators.

      The spring load cell has a hardened steel tube sliding in a bushing with hardened steel knife edge on top of the tube.  The tube rests on a coil spring on a lead screw which provides direct load reading via a dial indicator.  The height of the knife edge can be fixed at any position by a wing bolt.

Instruction manual is also included.

  • Deflection of beams with various supports and point loads.

  • Deflection of cantilever beam

  • Determination of flexural rigidity and elastic modulus.

  • Verification of static equilibrium.

  • Verification of the bending equation M/I = E/R

  • Beams with sinking supports.

  • Statically indeterminate beam with different loadings and supports.

  • Supporting frame
:  Aluminum profile and stainless-steel angle 1400 mm. long
  • ST 124 Vertical force spring support
:  3
  • ST 112 Built-in knife edge support
:  1
  • Weight hangers
:  4
  • Weights
:  1 lot
  • Beam length
:  1200 mm
  • Beam materials

-   Mild steel:  3
-   Aluminum and brass:  1
  • ST 131 Dial indicators
:  3x 0-20 mm range, 0.01 mm graduation


  • Net (unpacked) Shipping Dimensions WxLxH: 15 x 140 x 70 cm
  • Net Weight:  Approx. 55 kg
  • Beams of other sizes and materials can be supplied on request.

  • TM415-050      Computer Interface (computer not included)

    This includes TM415S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)

  • Other optional equipment, please contact manufacturer ([email protected])

  • TM415S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.



SIMILAR PRODUCTS

TM 411 STRUT BUCKLING APPARATUS

TM 411 STRUT BUCKLING APPARATUS

Enquiry

Video

Download

This bench top apparatus is used for studying buckling on struts under various end conditions.

The apparatus consists of two vertical columns where load is applied by a screw via a sliding support. Strut support for knife edge or built-in is a cylinder in a socket. Each strut has end conditions for knife-edge or built-in. Load on the strut is measured by a load cell and deflection is measured by a dial gauge. Side loading is by a weight hanger and weights. Height of loading beam is adjustable to accommodate different strut lengths.

Instruction manual is also included.

  • Determination of flexural rigidity and comparison with theoretical value.

  • Determination of flexural rigidity under different end conditions.

  • Determination of load VS deflection and crippling loads for strut of different

       lengths and cross sections.

  • Effects of side load and eccentric loading.

  • Basic frame
:  2 columns and sliding cross member with loading screw.
  • Maximum strut length
:  750 mm
  • Load measurement
:  Force digital display
  • Dial gauge
:  0-20 mm. x 0.01 mm. graduation.
  • Weight hanger

  • Weights
:  1 lot.
  • Strut supports
:  2 Knife edges
 :  2 Built-in
  • Struts specimens with knife edge ends:

- Mild steel:  6 ea. different lengths.
- Aluminium and brass:  Thickness (approx.) 6 mm, Width (approx.) 19 mm, Length: 750 mm
  • Power supply
:   220V, 1Ph, 50Hz. Other power supply is available on request.
  • Net (unpacked) Shipping Dimensions WxLxH: 25 x 25 x 105 cm
  • Net Weight:  Approx. 20 kg
  • Struts of other sizes and materials are available on request.

  • TM411-050    Computer Interface (computer not included)

                            This includes TM411S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)

  • Other optional equipment, please contact manufacturer

  • TM411S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.

SIMILAR PRODUCTS

TM 235 CHARPY IMPACT TESTING MACHINE, 150/300 J

TM 235 CHARPY IMPACT TESTING MACHINE, 150/300 J

Enquiry

Download

The impact testing machine is for determination of resistance to fracture of materials by Charpy test based on DIN50115 and DIN51222.

The machine is constructed with a heavy base and single support column. The pendulum is hung on ball bearings. Manual lifting of hammer is by two stage reduction gear. The impact energy can be adjustable for different capacity. A pendulum mechanical brake and safety guard are also provided.

Instruction manual is also included.

  • Determination of notched bar impact work.

  • Determination of notched bar impact strength.

  • Influence of notch form on impact work.

  • Influence of materials heat treatment, and temperature on impact work (optional).

  • Capacity
:     150 and 300 Joules
  • Scale graduation
:     1 and 2 Joule
  • Lift angle of hammer
:     145o
  • Striking velocity
:     5.378 m/s





  • Net (unpacked) Shipping Dimensions WxLxH: 60 x 95 x 140 cm
  • Net Weight:  Approx. 450 kg
  • TM232-001
Furnace for material heat treatment experiment
  • TM232-005

Specimens (pack of 5).

-  Notch                   :   ISO-V, ISO-U

  • TM235-011A
Additional motorized lifting device and a speed reducer with 220V, 1 Ph, 50Hz. power supply instead of manual lifting with a speed reducer.
  • TM235-012
Eddy current brake.
  • TM232-050
Computer Interface (computer not included)
                                          This includes TM232S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TM235S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.

SIMILAR PRODUCTS

TM 232 CHARPY IMPACT TESTING MACHINE, 25/50 J

TM 232 CHARPY IMPACT TESTING MACHINE, 25/50 J

Enquiry

Download

The impact testing machine is designed for determination of resistance to fracture of materials by charpy test based on DIN51222.

The machine is constructed with a heavy base and support columns.  The pendulum is hung on ball bearings. The impact energy can be adjustable for different capacity. A pendulum brake and safety guard are also provided.

Instruction manual is also included.

  • Determination of notched bar impact work.

  • Determination of notched bar impact strength.

  • Influence of notch form on impact work.

  • Influence of materials heat treatment, and temperature on impact work (optional).

  • Capacity
:     25 and 50 Joules
  • Scale graduation
:     0.25 and 0.5 Joule with maximum pointer.
  • Lift angle of hammer
:     145o
  • Striking velocity
:     3.825 m/s





  • Net (unpacked) Shipping Dimensions WxLxH: 40 x 65 x 120 cm
  • Net Weight:  Approx. 171 kg
  • TM232-001
Furnace for material heat treatment experiment
  • TM232-005
Specimens (pack of 5).
  • TM232-050
Computer Interface (computer not included)
                                                           This includes TM232S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TM232S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.

SIMILAR PRODUCTS

TM 221 CREEP TESTING MACHINE

Enquiry

Download

This equipment is used for testing materials with high creep such as lead and plastics.

A lever is pivoted to a column via ball bearing. Specimen is attached to one end of the lever while load is applied on the other end. Specimen extension is measured by a dial indicator. A glycol pack is provided to wrap the specimen and maintain the required test temperature.

Instruction manual is also included.

  • Creep phenomena of materials under different stresses and temperatures.

  • Lever ratio
:               8:1
  • Specimen enclosure
:               Clear acrylic
  • Weights
:               1 lot.
  • Dial indicator
:               10 mm x 0.01 mm graduation.
  • Thermometer
:               -10 to 50°C
  • Glycol pack







  • Net (unpacked) Shipping Dimensions WxLxH: 25 x 65 x 40 cm
  • Net Weight:  Approx. 15 kg
  • TM221-005Pb
Lead (Pack of 10).
  • TM221-005PE
Poly Ethylene (Pack of 10).
  • TM221-005PVC
Poly Vinyl Chloride (Pack of 10).
  • TM221-050
Computer Interface (computer not included)
                                                             This includes TM221S and significant sensor(s) instead of analog measuring instrument(s), data acquisition   (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TM221S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.
SIMILAR PRODUCTS

TM 211 FATIGUE TESTING MACHINE

Enquiry

Video

Download

This equipment is used for studying the effects of fatigue using a rotating cantilever specimen.

A spindle specimen is attached to one end of a rotating shaft held to the base by self aligned bearings. Load is applied on the spindle producing a sinusoidal bending stress. Digital revolution counter keeps account of the number of revolution when failure occurs. A limit switch is provided to stop the rotation when specimen fails.

Instruction manual is also included.

  • Influence of bending stress.

  • Influence of various speed

  • Influence of different radii at fracture section (optional).

  • Comparison of fatigue properties of different materials.

  • Wohler diagram.

  • Motor
:  0.37 kW, 2750 rpm (approx.)
  • Revolution counter
:  8 digits
  • Loading mechanism
:  Spring balance
  • Power supply
:  220V,  1 Ph,  50 Hz. Other power supply is available on request.








  • Net (unpacked) Shipping Dimensions WxLxH:  30 x 90 x 35 cm
  • Net Weight:  Approx. 38 kg
  • TM211-005
Specimens: Mild steel, brass or aluminium (pack of 10).
  • TM211-006
Specimens: different radii at fracture section.
  • TM211-010
Motor speed controller to provide variable test speeds.
  • TM211-015
Pulleys with synchronous belt to provide higher test speed.
  • TM211-050
Computer Interface (computer not included)
                                  This includes TM211S and significant sensor(s) instead of analog measuring instrument(s), data acquisition (capture, display, graph and/or data export), additional software function for real-time data logging with computer interface unit and WiFi feature for data logging and real-time display remotely on smartphone (iOS and Android)
  • TM211S
Learning Software
                                       to support both online/offline training with data calculation and analysis by manual data entry from analog measuring instruments.



SIMILAR PRODUCTS
